Ultrasonic Tube Filling Sealing Machine
| Dimension L x W x H | 1220mmx1030mmx1680mm |
| Weight | 300 Kg (Approx) |
| Input Voltage & Power | 220V, 2KW, Single Phase |
| Air Pressure req. | up to 5 Kg/cm square |
| Ultrasonic System | As per application |
| AC Drive | 0.5~1.0Kw with speed controller |
| Indexing System | 4 Station to 16 station |
| Productivity | 15-30 stroke/minute |
| Auto / Manual | Both Operation |
| Types | Pneumatic/Electronics |
An automatic ultrasonic tube filling sealing machine is a specialized equipment used in the packaging industry to fill and seal tubes with various products. It utilizes ultrasonic technology to perform the sealing process efficiently and effectively. Here’s an overview of how this type of machine typically operates:
- Tube Loading: Empty tubes are loaded into the machine’s tube holder or hopper. The machine is designed to handle a specific size and type of tube.
- Product Filling: The machine is equipped with a product filling system that accurately dispenses the desired quantity of product into each tube. This can be achieved through a piston, peristaltic pump, or other suitable filling mechanisms.
- Tube Orientation: The machine orients the tubes in the correct position for the filling and sealing process. This ensures that the product is deposited in the appropriate section of the tube.
- Ultrasonic Sealing: Ultrasonic technology is used to seal the filled tubes. The machine applies high-frequency ultrasonic vibrations to the tube’s opening, creating friction and heat that melt and bond the plastic or laminate material of the tube together. This creates a strong and secure seal.
- Coding/Printing: Some machines may have an integrated coding or printing system that allows for date coding, batch numbering, or other product-related information to be printed on the tube during the sealing process.
- Tube Ejection: Once the sealing process is complete, the sealed tubes are ejected from the machine. They can then be collected for further packaging or labeling.
Frequently Asked Questions (FAQs)
An Ultrasonic Tube Filling Sealing Machine is a specialized piece of equipment used for filling and sealing various types of tubes, such as those used for packaging creams, gels, and pastes. This machine employs ultrasonic technology for precise and efficient sealing.
This machine fills the tube with the desired product, and then it uses ultrasonic vibrations to create a secure and airtight seal on the tube’s open end. The ultrasonic energy softens and welds the tube material, ensuring a reliable closure.
Ultrasonic Tube Filling Sealing Machines are versatile and can handle a wide range of products, including creams, lotions, ointments, adhesives, and various semi-liquid or viscous substances.
- Precise and efficient filling
- Airtight and secure seals
- Minimal waste and product spillage
- Suitable for various tube sizes and materials
- Speeds up production and reduces labor costs
Products filled and sealed with this machine are commonly found in the cosmetics, pharmaceutical, food, and adhesive industries. These include creams, ointments, toothpaste, and various other products in tube packaging.
Ultrasonic Tube Filling Sealing Machines are adjustable to accommodate various tube sizes and materials, including plastic and laminated tubes. They can be configured to work with different tube dimensions and sealing requirements.
